Dierya 63 Dual Mode Keyboard Kit
Pls pay attention : Before soldering switches, pls test all keys(pls use tweezers or iron wire) and leds(If pcb can support 2pin single color led or rgb led) to make sure all keys can work properly, before soldering, if the pcb has any key problem, we can re-ship a new one, but after soldering, feel so sorry we cant re-ship it, we can help you repair it(buyer need pay the returining shipping fee). If you order our products, we assume that you agree to the above terms.
Pls pay attention: Keyboard Kit only, you still need solder switches by yourself, and this keyboard kit only support 3pin SMD switches.
Dierya 63 RGB PCB SPEC
*32 bit MCU
*Built in 8M Flash
*Dual Mode, support bluetooth 4.0 wireless mode
*3 256*256*256LED driver chip supports 16.8Million colors LED ,support kinds of led effect.
*Type-C Usb cable or Micro Usb cable.
*Li-Battery inside(1500mAh)
Connection with Device: Make sure bottom Battery button is on,press Fn+Q W or E for 3s, open BT mode, then you can find Dierya ar your PC or Phone. After first successful connection, next time, you can press fn+ Q W or E to a quick connection with your device.
Changing Cable mode and Bluetooth mode: press Fn+R
Fn+1-+=F1-F12
Fn+Esc=`
Fn+Shift+Esc=~
Fn+Arrow Key=Light Speed and brightness
Fn+?=Led Effect Mode Changing
Fn+Spacebar=Led Effect Pause Mode
Fn+L Ctrl=Change Capslock and L Ctrl
Fn+P=Print
Fn+[=Home
Fn+]=Delete
Fn+Win=Win Lock
Before using, make sure you has soldered button and Electronic Components like following picture:
