[Hot-Swap Version] D84 V2 75% Gasket Mount Mechanical Keyboard DIY KIT

Building Tutorial: Link

Specs

• D84 version 2 75% layout

• Mounting styles: Gasket Mount

• Designer: KBDfans Wei

• Case: D84 V2 top aluminum case and bottom aluminum/ acrylic case

• Weight bar: Aluminum material, the color is the same as the top case

• Hot-swap PCB: KBD75 hot swap PCB (SKU: DP3259)(Type-C interface, with RGB underglow, no Per-key RGB) , fits with KBD75 v3/ v3.1, D84 keyboard. Fixed layout (84keys), not support other layouts.

• Plate: D84 V2 Brass/Aluminum/Polycarbonate Plate

• Stabilizers: Cherry screw-in stabs 60 sets (SKU: DP0003)

• Foams: Case foam + PCB foam + Gaskets

• *Reminds: Due to the optimization of the internal structure of the case, the Plate, Case of D84 version 1 and version 2 are incompatible with each other.

Include

• Case x1

• PCB x1

• Plate x1

• Stabilizers set x1

• USB A to C Cable x1

• PCB foam x1

• Case foam x1

• Gaskets set x1

• Rubber feet and screws

Flash Manual

• QMK Flash Manual Link

• Hot-swap PCB firmware: kbdfans_kbd75hs_via.hex

• Solder PCB firmware: kbdfans_kbd75_rev2_via.hex

Layout
